CRL R7015 Jalousie Window Operator with Break-Off Link Arm

• Non-Handed

Spindle Applications

3/32″ (2.4 mm)

Spline Size

5/16

Body Width

1/2

Inner Mounting Hole (Inches)

2-1/8

Jalousie Operator Spindle Length

3/32

Operator Height (Inches)

4-7/8

Inner Mounting Hole

2-1/8 in. (54 mm)

Operator Height

4-7/8 in. (123.8 mm)

Product Overview CRL Jalousie Window Operator with Break-Off Link Arm is a non-handed rack operator. It comes with an adjustable break off link extensions arm for universal; applications. It is side mounted with 2-1/8″ (54 mm) screw holes. The 3/32″ (2.4 mm) long spindle has a 5/16″ (7.9 mm) spline size. DS 07/08/2016 From Manufacturer
This non-handed CRL Louver Window Operator is a rack operator with an adjustable break-off link extension arm for universal application. It is side mounted with 2-1/8″ (54 mm) screw holes. The 3/32″ (2.4 mm) long spindle has a 5/16″ (7.9 mm) spline size. This unit comes with a crank handle.
