Pemko 4301CRL 36 36" Surface Mounted Automatic Door Bottom with EPDM Clear Aluminum Finish Clear Anodized Aluminum 4301CRL36

• Pemko Products Provide an Energy Efficient Door Solution
• BHMA Grade: Grade 1
• Fasteners: Sheet Metal Screws
• Pemko Products Undergo Rigorous Testing to Ensure That They Meet or Exceed the Industry Standards
• Pemko Offers Many Fabrication Options to Fit Specific Job Requirements
• Mounting Hardware Included
• Limited 5 Year Warranty

Finish

Clear Anodized Aluminum

Series

Door Bottoms

Length

36″

Width

29/32″

Size

29/32″ X 1-25/32″

Insert Color

Black

Manufacturer Parent

Assa Abloy

Finish Description

Clear Anodized Aluminum

For Use With

Architectural Doors

Product Width

29/32 Inch

Function

Automatic Door Bottom

Sub-Series

4301CRL-36

ADA Compliant

No

Product Height

1-25/32 Inch

Standards

Air Infiltration Tested ASTM E-283-04; Sound Tested ASTM E90; BHMA Certified ANSI/BHMA A156.22; Smoke Tested UL 1784; NFPA 105-2013; Fire Rated UL10B, UL10C Positive Pressure

Insert Replacement Part Number

E4303

Product Type

Door Accessory

Features

Recommended Gap Under Door is 1/2″; Maximum Drop is 3/4″; For Semi Mortised Applications

Product Material

6063-T6 Aluminum Alloy

Product Length

36 Inch

Warranty

5 Year

Insert Type

Sponge EPDM Insert

Finish Family

Aluminum

Bristle Length

1.7813

Insert Material

Aluminum

Length (Inch)

36

Overall Length (Inch)

36

PSC Code

5640

Vendor Drop Ship

N

Product Overview 36″ Surface or Semi-Mortised Mounted Automatic Door Bottom in Clear Anodized Aluminum with EPDM Insert
